VISLAT 8-Panel Large LED DJ Booth P3.91 Festival Stage Display

The VISLAT 8-panel large LED DJ booth delivers a full festival-scale P3.91 stage wall that still packs into standard road cases.

Key specifications

• Pixel pitch: P3.91 mm, effective from roughly 3 metres and ideal at 5-15 metres
• Brightness: 1,000 nits with a 3,840 Hz refresh rate for broadcast and camera capture
• Panels: eight 500 x 500 mm die-cast cabinets, around 4 m wide x 1 m high per row
• Structure: bolt-together cabinets with hanging or ground-stack options
• Ingress protection: IP40 indoor-rated, with spare modules supplied for tour spares kits
• Control: HDMI, DVI or SDI through a standard sending card and video processor, with multiple inputs for live playback and playback-backup

Typical applications

It is aimed at festival and concert stages, large club installations, conference main stages, esports events and rental houses that need a reliable indoor wall in the 4-8 m class.

Warranty and engineering support

Every VISLAT 8-panel large LED DJ booth leaves our Shenzhen factory with a 3-year warranty covering LED modules, power supplies and control components, together with 24/7 remote engineering support for configuration, signal mapping and on-site troubleshooting. Spare parts and replacement modules are available for the full service life of the product.
